£92.90 ex VAT (£111.48 inc VAT)
Coupling-jointed cast iron soil and waste system, compatible with BS 416 pipework. Bellmouth. Cast iron, supplied factory coated.
Product code: MS4070.
UK delivery from £30. Fittings are despatched boxed. See delivery rates.
The Tuscan Mechanical BS416 Soil range is a coupling-jointed cast iron soil and waste system, dimensionally compatible with BS 416 pipework. Plain-ended pipes and fittings are joined with bolted ductile iron couplings, so there are no caulked or sealed sockets. A stack goes together quickly, and individual fittings can be taken out later without disturbing the rest of the run. Conversion couplings join it to existing socketed LCC pipe, which makes it a practical choice for repairs and extensions to older stacks as well as new work.
A 100mm bellmouth gully inlet with a wide cast iron mouth. It takes a grating or a solid cover.
Product code MS4070. Nominal weight 2.9 kg.
Typical use: Collecting surface water or receiving a pipe discharge at ground level.
| Item | Product code | Nominal weight |
|---|---|---|
| Bellmouth | MS4070 | 2.9 kg |
Often used with: Bellmouth Grating, Bellmouth Cover, 15° Short Radius Bend.
Comparing systems? Our guide to choosing a cast iron soil pipe system sets out how LCC, Traditional Express, mechanical BS 416 and EN 877 differ.
Prices are per item, excluding VAT and delivery. Stock items are usually dispatched within 5 to 7 working days. For a full stack or drainage schedule, or advice on the right fittings, call 0333 987 4452 or use the contact form.
The product code is MS4070. Nominal weight 2.9 kg.
A plain grating to collect surface water, or a solid cover with a rubber seal where it takes a pipe connection only.
