£19.80 ex VAT (£23.76 inc VAT)
Coupling-jointed cast iron soil and waste system, compatible with BS 416 pipework. Bellmouth Grating. Cast iron, supplied factory coated.
Product code: MS8077.
UK delivery from £30. Fittings are despatched boxed. See delivery rates.
The Tuscan Mechanical BS416 Soil range is a coupling-jointed cast iron soil and waste system, dimensionally compatible with BS 416 pipework. Plain-ended pipes and fittings are joined with bolted ductile iron couplings, so there are no caulked or sealed sockets. A stack goes together quickly, and individual fittings can be taken out later without disturbing the rest of the run. Conversion couplings join it to existing socketed LCC pipe, which makes it a practical choice for repairs and extensions to older stacks as well as new work.
A 200mm plain cast iron grating for the bellmouth gully inlet.
Product code MS8077. Nominal weight 1.8 kg.
Typical use: Letting surface water into a bellmouth gully inlet.
| Item | Product code | Nominal weight |
|---|---|---|
| Bellmouth Grating | MS8077 | 1.8 kg |
Often used with: Bellmouth, Bellmouth Cover.
Comparing systems? Our guide to choosing a cast iron soil pipe system sets out how LCC, Traditional Express, mechanical BS 416 and EN 877 differ.
Prices are per item, excluding VAT and delivery. Stock items are usually dispatched within 5 to 7 working days. For a full stack or drainage schedule, or advice on the right fittings, call 0333 987 4452 or use the contact form.
The product code is MS8077. Nominal weight 1.8 kg.
Use the grating where the gully collects surface water, and the solid cover where it takes a pipe connection only.
Our cast iron hopper heads are available with 65mm, 75mm and 100mm round outlets, 75mm, 100mm and 125mm square outlets, and 100x75mm, 125x100mm and 150x125mm rectangular outlets, to match the downpipe already on site or specified for the project.
Yes. Bespoke copy casting is a core service at Tuscan Foundry Products. We can replicate any cast iron gutter, downpipe, hopper head, or fitting from drawings, detailed photographs, or a physical sample or surviving section. Each commission is assessed individually. Lead time is typically 12 to 14 weeks, and quantities as low as a single piece can be considered depending on pattern-making costs.
Hopper heads are supplied in red oxide primer ready for on-site painting, or pre-finished in black. A full range of Heritage Colours in traditional linseed oil paint is also available on request — please contact us for the swatch chart.
Yes. All our mild steel brackets are supplied in either silver or black zinc plate. This coating protects the metal however, both will need painting prior to installation.
We have chosen to use zinc plating for two reasons; firstly that it is a more environmentally friendly than galvanising and secondly that it does not block up the threaded part of the rise and fall cups in the way that galvanising does.
Our standard spike or sturt length is 300mm (12″). Other sizes are available upon request.
Prices for each item are shown on the product pages, ex VAT. For a full schedule and quotation, send drawings or photographs showing the stack height and the connections, then call 0333 987 4452 or use the contact form.
