Price range: £36.20 through £137.00 ex VAT (£43.44 – £164.40 inc VAT)
Socketless cast iron soil, waste and rainwater system made to BS EN 877. Stack Support Bracket, available in 70mm, 100mm, 150mm, 200mm. Cast iron, supplied factory coated.
Product codes: HS3057 (70mm), HS4057 (100mm), HS6057 (150mm), HS8057 (200mm).
UK delivery from £30. Fittings are despatched boxed. See delivery rates.
Tuscan EN877 Soil is a socketless cast iron soil, waste and rainwater system made to BS EN 877. Plain-ended pipes and fittings are joined with stainless steel or ductile iron couplings, giving a slim, continuous line on a façade or in a service riser. Cast iron is non-combustible, quiet in use and very long-lived. That is why it remains the specification of choice for heritage buildings, tall stacks, and anywhere acoustic performance or fire safety matters.
A stack support bracket with a gasket. It carries the collar of a stack support pipe and fixes back to the structure.
Available in 4 sizes, from 70mm to 200mm. Nominal weights run from 1 kg (70mm) to 2.2 kg (200mm).
Typical use: Intermediate support points on tall vertical stacks.
| Size | Product code | Nominal weight |
|---|---|---|
| 70mm | HS3057 | 1 kg |
| 100mm | HS4057 | 1.4 kg |
| 150mm | HS6057 | 1.8 kg |
| 200mm | HS8057 | 2.2 kg |
Often used with: Stack Support Pipe, Stack Support Console, Cantilever Bracket.
Comparing systems? Our guide to choosing a cast iron soil pipe system sets out how LCC, Traditional Express, mechanical BS 416 and EN 877 differ.
Prices are per item, excluding VAT and delivery. Stock items are usually dispatched within 5 to 7 working days, and non-stock sizes within 7 to 10 working days. For a full stack or drainage schedule, or advice on the right fittings, call 0333 987 4452 or use the contact form.
It is available in 70mm (HS3057), 100mm (HS4057), 150mm (HS6057), 200mm (HS8057).
The weight of the stack above that point, through the collar of the stack support pipe.
| Size | 70mm, 100mm, 150mm, 200mm |
|---|
Hopper heads are supplied in red oxide primer ready for on-site painting, or pre-finished in black. A full range of Heritage Colours in traditional linseed oil paint is also available on request — please contact us for the swatch chart.
LCC is traditional cast iron socket-and-spigot soil pipe made to BS 416-1:1990. Each length has a socket at one end and a spigot at the other, and joints are packed with caulking cord and finished with a jointing sealant. It is supplied with a black bitumen coating and is the like-for-like choice for external soil stacks on Victorian and Edwardian buildings. See the Traditional LCC range.
The Regent H1 is well suited to Victorian and Edwardian terraces, listed commercial buildings, civic and institutional properties, and ecclesiastical buildings where a traditional funnel-form hopper is architecturally appropriate. Its multi-faceted tapering body reads as period-accurate on Gothic and classical building types alike, and it is a commonly specified choice for conservation and listed building projects across the UK.
For rooflights directly above a worktop or sink, a telescopic screw-jack hand winder is the most practical choice. Available in polished brass, satin chrome, and polished chrome, these openers allow controlled ventilation from a fixed handle position without requiring a pole. The 150mm or 250mm size is typically appropriate for standard-height kitchen rooflights.
A hit and miss vent has a sliding plate on the reverse of the grille that can be moved to open or close the ventilation apertures. This allows airflow to be regulated without removing or replacing the grille. The vent can be fully open, partially open, or fully closed depending on ventilation requirements.
The Iron Works Patterned Hit & Miss Vent suits Victorian and Edwardian buildings where decorative cast iron or brass ventilation grilles were part of the original specification — including terrace houses, civic buildings, churches, entrance halls, and estate properties. It is appropriate on listed buildings and conservation area properties as a like-for-like decorative vent replacement, and on new heritage-quality construction where period detailing is required.
The Calnethorpe is designed for formal classical and Georgian elevations where scale and material authenticity matter — large townhouses, country houses, manor houses, and institutional buildings. It is also widely specified for new-build heritage projects where cast iron rainwater goods are required to conservation standard.
The Ornamental Airbrick is most appropriate on Victorian Gothic buildings — churches, chapels, vicarages, almshouses, collegiate buildings, and high-specification estate architecture — where decorative ironwork was part of the original design. It suits listed building replacements in kind and heritage new build where period accuracy in detailing is expected.
Satin chrome has a brushed, low-sheen finish suited to contemporary interiors, while polished chrome has a bright mirror finish. Both are available in the telescopic hand winder range at Tuscan Foundry. The choice typically depends on the existing ironmongery specification.
The physical properties of cast iron are sustained throughout its working life, so with proper maintenance we'd expect our gutters and pipes to last over 100 years under normal conditions.
