LCC Soil Pipe – Plain 610mm

The 610mm plain LCC soil pipe is the shortest standard length in our non-eared traditional cast iron soil range. It completes a stack without site cutting and covers the short runs between fittings.

Plain pipe has a spigot and socket but no cast-on ears, so it is fixed independently of the casting with holdfasts or holderbats. Loose ears can also be fitted where an eared fixing is wanted at a particular joint. Joints are caulked and sealed in the traditional way.

Plain soil pipe suits elevations where fixings need to be positioned to the masonry rather than the pipe joints, and walls where historic holdfasts or holderbats survive. Combine it with 914mm, 1219mm and 1829mm lengths to make up any height.

Cast iron to BS 416-1:1990, supplied with a black bitumen coating as standard. Bitumen cannot be reliably overpainted; where the stack is to be painted, ask about our Traditional Express push-fit system.

Suitable for listed buildings and conservation area work. For specification advice, a full schedule or a quotation, call 0333 987 4452 or use the contact form.

Comparing push-fit and caulked soil pipe? Read our Traditional Express vs LCC guide or the soil pipe FAQs.

Comparing systems? Our guide to choosing a cast iron soil pipe system sets out how LCC, Traditional Express, mechanical BS 416 and EN 877 differ.
