Shop / Heating & Radiators / Victorian Cast Iron Radiators / 4 Column Cast Iron Radiator (485mm h V4-48) Painted
Cast Iron Victorian Radiator Red
Victorian Cast Iron Radiator Coloured
Victorian Cast Iron Radiator Colours
CODE V4-48-PAINTED Category Victorian Cast Iron Radiators

4 Column Cast Iron Radiator (485mm h V4-48) Painted

£127.50 – £1,275.00Price range: £127.50 through £1,275.00 +VAT

Made from quality cast iron our forged radiator delivers heat through out the house. The cast iron radiator combines classic authentic styling with modern reliability and comfort.

Clear

The Victorian 4 Column cast iron radiator at 485mm height (V4-48) is a low-to-mid height radiator particularly suited to under-window installation, skirting-level positions, and rooms where the wall space above the radiator is occupied by windows, shelving, or other features. The four-column profile replicates the original Victorian pattern — proportionate and period-appropriate even in a compact section count.

This variant is supplied painted — pre-finished in a colour coat, ready to install. The painted finish is ideal where the installation is going directly to completion without further decoration.

Supply and assembly: Supplied in individual sections. Available pre-assembled up to 20 sections ready for installation. Supplied as a floor-standing version with integrated feet as standard — the wall-mounted only version must be requested at time of order. The radiator is supplied with ½” connections. Valves are not included and must be purchased separately if required.

Feet positions: Up to 20 sections — 2 feet, one at each end. Odd numbers 21–39 sections — 3 feet, one at each end and one centrally. Even numbers 22–40 sections — 4 feet, one at each end and 2 evenly spaced. Wall bracket requirements increase proportionally for larger radiators.

For specification support or a project quotation, call Tuscan Foundry Products on 0333 987 4452.

Additional information

Sections

3 Sections, 4 Sections, 5 Sections, 6 Sections, 7 Sections, 8 Sections, 9 Sections, 10 Sections, 11 Sections, 12 Sections, 13 Sections, 14 Sections, 15 Sections, 16 Sections, 17 Sections, 18 Sections, 19 Sections, 20 Sections, 21 Sections, 22 Sections, 23 Sections, 24 Sections, 25 Sections, 26 Sections, 27 Sections, 28 Sections, 29 Sections, 30 Sections

Colour

Ruby Red, Ultramarine Blue, Cobalt Blue, Steel Blue, Bronze, Grass Green, Grey Aluminium, Moss Green, Pearl Dark Grey, Gun Metal, Light Grey, Slate Grey, Jet Black

FAQ Categories

  • Cast Iron Airbricks
  • Cast Iron Airvents
  • Cast Iron Hopper Heads
  • Gutter & Pipe Brackets
  • Gutters & Pipes
  • Heating
  • Rooflight Openers
All FAQ
My builder has calculated out our heating requirement in each room of our house in BTU’s. Can you tell me what BTU’s stand for, and is this different to KW.

My builder has calculated out our heating requirement in each room of our house in BTU’s. Can you tell me what BTU’s stand for, and is this different to KW.

BTU stand’s for British Thermal Units. This was the old (Imperial) measurement for heat in connection with plumbing. Although BTU’s is a term still commonly used within the heating and plumbing, the industry is now going over to KW’s Kilowatts.

What finish options are available for rooflight opener handles?

What finish options are available for rooflight opener handles?

Rooflight opener handles are available in polished brass, polished chrome, and satin chrome finishes. The polished brass version is the most popular choice for heritage and period interiors. For the full range, visit tuscanfoundry.com or call 0333 987 4452.

What finishes are available on your cast iron hopper heads?

What finishes are available on your cast iron hopper heads?

Our cast iron hopper heads are available in a choice of finishes including primer, painted, and specialist heritage finishes. Please call us on 0333 987 4452 or submit an enquiry to discuss the right finish for your project.

My house has a plastic guttering system. Can I use your brackets to replace my exisiting broken ones?

My house has a plastic guttering system. Can I use your brackets to replace my exisiting broken ones?

Our brackets are more commonly used on cast iron rainwater systems. Unlike plastic, cast iron is heavy and the weight keeps the gutter in position. As such our brackets do not normally have retaining clips which could lead to plastic or lightweight gutters blowing out of the bracket. The profile of your gutter should match that of our bracket but without the weight to keep it in place you may well encounter problems in bad weather.

Where can I purchase cheap cast iron gutter and pipe?

Where can I purchase cheap cast iron gutter and pipe?

With National Maintenance week fast approaching (18th – 25th November 2011), Tuscan Foundry Products Ltd have decided to help period property owners look after rainwater systems by offering big discounts on selected cast iron gutters, pipes and fittings.

Friday 25th November is designated as National Gutters Day and on this particular day, homeowners are encouraged to check their systems for evidence of damage. Repairing sections of damaged cast iron gutter and pipe can help avoid potentially thousands of pounds of damage to brickwork.

Tuscan is offering these savings across a range of profiles and includes both primer and painted stock. The offers will only be available whilst stocks last so visit our website to view our discounted cast iron rainwater goods today.

For more information concerning National Maintenance Week visit the Society for the Protect of Ancient Buildings (SPAB) at www.maintainyourbuilding.org.uk

What sizes are the Iron Works Patterned Hit & Miss Vents available in?

What sizes are the Iron Works Patterned Hit & Miss Vents available in?

Available in two sizes: 225mm x 82mm (single airbrick course height) and 225mm x 150mm (double course height). Both sizes fit standard brick coursing positions and install flush into the wall face.

What is the difference between satin chrome and polished chrome rooflight openers?

What is the difference between satin chrome and polished chrome rooflight openers?

Satin chrome has a brushed, low-sheen finish suited to contemporary interiors, while polished chrome has a bright mirror finish. Both are available in the telescopic hand winder range at Tuscan Foundry. The choice typically depends on the existing ironmongery specification.

What sizes are available for the Cast Iron Louvre Airbrick?

What sizes are available for the Cast Iron Louvre Airbrick?

The Cast Iron Louvre Airbrick (F020802AFC) is available in 225mm × 75mm, 225mm × 150mm, and 225mm × 225mm — standard brick course heights. All sizes share a consistent depth for straightforward like-for-like replacement of original cast iron louvre airbricks.

Are ornamental cast iron vents suitable for listed buildings?

Are ornamental cast iron vents suitable for listed buildings?

Yes. Cast iron ornamental vents in period patterns are frequently specified on listed buildings and conservation area properties as like-for-like replacements for original Victorian ironwork. Conservation officers generally accept cast iron in period patterns without objection. We can supply specifications to support planning and listed building consent applications.

What is the difference between polished chrome and satin chrome rooflight openers?

What is the difference between polished chrome and satin chrome rooflight openers?

Polished chrome has a bright mirror finish, while satin chrome has a brushed, low-sheen appearance. Both are available in the telescopic hand winder range. The finish choice typically depends on the ironmongery specification for the project.
