Price range: £182.50 through £256.96 +VAT
Cast iron rainwater ornamental head H1 and cast iron hopper head H1. Castings for period, listed and traditional buildings.
(Bespoke cast iron hopper heads maufactured to order)
The Regent Cast Iron Hopper Head No.1 is one of the most recognisable forms in the traditional rainwater catalogue — a wide-shouldered, multi-faceted body that narrows dramatically to a slender outlet, with the kind of confident silhouette you see on Victorian terraces, civic buildings, and well-detailed country houses across the UK.
The H1 is cast with a flat back for wall mounting, with integral fixing holes, and offered in three pipe sizes: 65mm (2.5″), 75mm (3″), and 100mm (4″). At its largest — for 100mm pipe — the unit measures 355mm wide by 230mm deep and 240mm high, making it a substantial and visually authoritative component on larger drainage runs. The smaller 65mm and 75mm variants share the same 305mm width and 197mm depth, appropriate for secondary stacks, outbuildings, and properties where the downpipe run is lighter.
The multi-faceted tapering body is the defining characteristic of this hopper: it gives the H1 depth and shadow without relying on applied ornament. On Victorian townhouses, listed commercial properties, and Gothic-influenced ecclesiastical buildings, this form reads as period-accurate and architecturally coherent.
Manufactured to order in solid cast iron in the UK. Available in Standard Black and Heritage Colour finishes, with a linseed oil paint option for conservation and listed building projects.
Pipe connections: Round 65mm, 75mm, 100mm, 150mm.
For listed buildings and conservation projects, call 0333 987 4452 or visit tuscanfoundry.com.
| Weight | 3 kg |
|---|---|
| Size/Finish | Primer 305w x 197d x 210h to 65mm, Primer 305w x 197d x 210h to 75mm, Primer 335w x 230d x 240h to 100mm, Black 305w x 197d x 210h to 65mm, Black 305w x 197d x 210h to 75mm, Black 335w x 230d x 240h to 100mm |
Yes. All our mild steel brackets are supplied in either silver or black zinc plate. This coating protects the metal however, both will need painting prior to installation.
We have chosen to use zinc plating for two reasons; firstly that it is a more environmentally friendly than galvanising and secondly that it does not block up the threaded part of the rise and fall cups in the way that galvanising does.
The Antique Black cast iron version is suitable for external use. The Polished Lacquered version is best suited to interiors or sheltered external locations where the polished finish will be protected from weathering. The Polished Brass version is suited to interior and semi-exposed locations. For external applications on exposed elevations, the Antique Black finish is the recommended specification.
Yes. Cast iron hopper heads are the historically appropriate choice for listed buildings, and are generally preferred by conservation officers and local planning authorities over modern plastic alternatives. Tuscan Foundry cast iron hopper heads are manufactured in solid grey iron and are suitable for use on listed buildings and within conservation areas. A linseed oil finish is also available, which is particularly appropriate for sensitive heritage projects.
Cast iron hopper heads from Tuscan Foundry are available in Standard Black (a factory-applied primer and topcoat finish) and Heritage Colours. A linseed oil paint finish is also available, providing a vapour-permeable, historically authentic coating that is particularly appropriate for listed buildings and conservation projects. Full finish specifications are available from the team.
Tuscan Foundry supplies screw-jack rooflight openers in polished brass, satin chrome, and polished chrome finishes. Options include telescopic hand-winder openers in 150mm, 250mm, and 300mm sizes, fixed screw-jack stays, and pole-operated handles for high-level rooflights. All are designed for timber-framed rooflights and skylights.
The satin chrome telescopic rooflight hand winder opener is available to order at tuscanfoundry.com. For project or volume enquiries, call 0333 987 4452 or use the contact form on our website.
The Ornamental Airbrick (OAB) is available in three sizes: 225mm × 75mm (2.8kg), 225mm × 150mm (4.1kg), and 225mm × 225mm (5.8kg). All sizes have a uniform depth of 75mm, making them consistent to install across a subfloor ventilation course.
Prices for our rooflight openers are shown on each product page. If you need multiple items, have a specific project in mind, or want to discuss compatibility, please call 0333 987 4452 or use the contact form at tuscanfoundry.com and we will be happy to assist.
A pole winder opener has a fixed-length arm, making it suited to standard rooflight positions with a consistent throw. A telescopic opener has an adjustable shaft, allowing it to accommodate varying rooflight positions and throw requirements. For guidance on which suits your project, call 0333 987 4452.
Yes. The Louvre Airbrick is dimensioned to standard brick course openings and is suitable for direct replacement of worn, broken, or missing original cast iron louvre grilles. If you are unsure of the size required, measure the opening in the brickwork rather than the existing damaged grille.
