The Archant No.516 is the most unusual casting in the range and, on the right building, the most rewarding. It is not shaped like a hopper at all. It is shaped like a length of balustrade.
A moulded plinth runs the full width of the casting, with a matching cornice above. Between them sits an open arcade of turned balusters, cast in the round and genuinely pierced, so daylight passes through. The arcade is flanked at each end by a square panel carrying a rosette — a paterae roundel of the kind found in classical friezes — and the whole composition is terminated by a ball finial at either end.
The effect is that the rainwater head reads as a fragment of parapet balustrade that happens to collect water. On a building with an actual balustraded parapet, a pedimented centrepiece, or classical detailing at high level, it resolves a problem that usually has no good answer: how to place a hopper on a principal elevation without it looking like an afterthought bolted to the architecture.
This is a pattern for significant buildings — country houses, civic and institutional work, orangeries and garden buildings, and high-quality new construction in a classical idiom. It is emphatically not a pattern for a modest elevation, where its width and its ornament would overwhelm everything around it.
Cast in solid iron to BS 460:2002 and supplied in primer or black as standard, with heritage colours and traditional linseed oil finishes available on request. The pierced balusters reward a finish applied with care; we are happy to advise on preparation and coating.
Pipe connections: 65mm, 75mm and 100mm round; 75×75mm, 100×100mm and 125×125mm square; 100×75mm, 125×100mm and 150×125mm rectangular.
Suitable for listed buildings and conservation areas. Call 0333 987 4452 to discuss suitability for a specific elevation.
| Finish | Primer, Black |
|---|---|
| Connection | 65mm Round, 75mm Round, 100mm Round, 75mm x 75mm Square, 100mm x 100mm Square, 125mm x 125mm Square, 100mm x 75mm Rectangular, 125mm x 100mm Rectangular, 150mm x 125mm Rectangular |
Hopper heads are supplied in red oxide primer ready for on-site painting, or pre-finished in black. A full range of Heritage Colours in traditional linseed oil paint is also available on request — please contact us for the swatch chart.
Our cast iron hopper heads are available in a standard primed and black-painted finish, ready for on-site topcoats. Heritage colour finishes and factory-applied linseed oil paint are available on request. Linseed oil paint is a vapour-permeable, period-appropriate finish particularly well suited to listed buildings and conservation area properties.
Linseed oil paint is the most appropriate finish for cast iron guttering on listed and historic buildings. It is breathable, flexible, and penetrating — qualities that suit the movement characteristics of cast iron through seasonal temperature changes. Tuscan Foundry Products offers a curated range of heritage linseed oil colours. For modern applications, a high-quality exterior oil-based paint system over a metal primer is also acceptable.
