The Elmsby No.169 is a wide head with a gently bowed front and a side outlet — drawn for the positions where a conventional hopper simply cannot be made to work.
The front face curves outward in a shallow bow rather than sloping flat, which adds capacity without adding projection and softens the casting against the wall. The outlet is taken from the side, so the downpipe can be led away laterally before dropping.
That side discharge is the reason to specify it. On historic buildings the pipe frequently cannot fall straight — a plinth, a buttress, a bay, a string course or a boundary intervenes — and the usual solution is a stack of offsets below the hopper, each one a joint exposed to weather and a place for debris to lodge. Taking the discharge sideways at the head itself removes that problem at source.
It suits period domestic and estate buildings, courtyards and passages, and any elevation where the downpipe route is constrained.
Cast in solid iron to BS 460:2002, supplied in primer or black as standard, with heritage colours and traditional linseed oil finishes available on request.
Pipe connections: 65mm, 75mm and 100mm round; 75×75mm, 100×100mm and 125×125mm square; 100×75mm, 125×100mm and 150×125mm rectangular.
Suitable for listed buildings and conservation areas. Send us a photograph of the position and we will confirm the arrangement. Call 0333 987 4452.
| Finish | Primer, Black |
|---|---|
| Size | 300w x 197d x 222h to 65mm, 300w x 197d x 222h to 75mm, 300w x 197d x 222h to 100mm, 300w x 197d x 222h to 100mmx75mm, 300w x 197d x 222h to 125mmx100mm, 300w x 197d x 222h to 150mmx125mm, 300w x 197d x 222h to 75mmx75mm, 300w x 197d x 222h to 100mmx100mm, 300w x 197d x 222h to 125mmx125mm |
Yes — we strongly recommend painting all products before installation to ensure full coverage on every surface, which reduces long-term maintenance. Standard Premier Rainwater products are supplied in a grey metal primer with rust inhibitors and need two undercoats and one top coat (or one undercoat and two top coats) of a good quality exterior paint.
The Paxton H82 is a large-format hopper with decorative collar mouldings, making it particularly well suited to late Victorian and Edwardian buildings where the rainwater system forms part of the architectural composition. Typical applications include commercial heritage buildings, civic buildings, large detached houses, institutional premises, and warehouse conversions where a more substantial fitting is appropriate.
Yes. Bespoke copy casting is a core service at Tuscan Foundry Products. We can replicate any cast iron gutter, downpipe, hopper head, or fitting from drawings, detailed photographs, or a physical sample or surviving section. Each commission is assessed individually. Lead time is typically 8 to 10 weeks, and quantities as low as a single piece can be considered depending on pattern-making costs.
Prices vary depending on size and finish. To get a quotation, please call 0333 987 4452 or use the contact form on the Tuscan Foundry website. The team can advise on the right specification for your project and provide a written quote.
BS 460:2002 is the British Standard governing cast iron rainwater goods — gutters, pipes, and fittings. It sets the dimensional tolerances, materials, and performance requirements a component must meet, so that joints seal, sections align, and the system performs as a whole rather than as isolated parts. All Tuscan Foundry Products components are manufactured to comply with BS 460:2002, which is worth citing directly in specification documents and listed building consent applications. The same manufacturing standard applies to bespoke and copy-cast work, even where the profile itself isn't from our standard range.
This opener is particularly well suited to period and heritage properties — Georgian and Victorian terraces, conservation area houses, traditional orangeries, and listed buildings where a brass finish is required to complement existing ironmongery. It is compatible with Lumen Rooflights and most timber-framed skylights.
Yes. Cast iron ornamental vents in period patterns are frequently specified on listed buildings and conservation area properties as like-for-like replacements for original Victorian ironwork. Conservation officers generally accept cast iron in period patterns without objection. We can supply specifications to support planning and listed building consent applications.
Tuscan Foundry's cast iron hopper heads are available in Standard Black and Heritage Colour finishes. A linseed oil paint finish is also offered — a sustainable, vapour-permeable option particularly appropriate for listed buildings and conservation projects. Heritage colour swatches are available from the team on request.
BTU stand’s for British Thermal Units. This was the old (Imperial) measurement for heat in connection with plumbing. Although BTU’s is a term still commonly used within the heating and plumbing, the industry is now going over to KW’s Kilowatts.
Yes. Cast iron hopper heads are the historically correct choice for listed and period buildings, and a like-for-like cast iron replacement is generally accepted without objection by conservation officers. We manufacture to BS 460 for genuine heritage character and durability.
