£226.40 – £246.30Price range: £226.40 through £246.30 ex VAT (£271.68 – £295.56 inc VAT)
Traditional wheelhead corner thermostatic radiator valve (TRV) and lockshield set for pipes coming from the wall, left- or right-hand, in polished brass or chrome. 15mm copper pipe. One set per radiator.
UK delivery from £30. Fittings are despatched boxed. See delivery rates.
The Belgrave is a traditional wheelhead radiator valve: a turned body with a rounded lower section and tapered upper section, topped by a wheel handle in a dark wood tone, in the pattern found on radiators from the late Victorian period onwards. This is the corner thermostatic version, for pipes that come out of the wall, with the thermostatic element set within the wheelhead so the valve keeps its period appearance. It suits our Victorian, Edwardian, Board School and ornate cast iron radiators.
Each set is a pair: a thermostatic valve (TRV) for one end of the radiator, and a matching lockshield for balancing at the other. The thermostatic head lets each room be set to its own temperature, which is what current Building Regulations expect on new and replacement radiators in most rooms. Turning the head sets the room temperature up to about 30°C; turned fully clockwise, it closes but still opens below about 6°C to give frost protection. The thermostatic valve is not bi-directional: it must be fitted on the flow pipe, or it may be noisy in use. Valves fit 15mm copper pipe with ½” BSP radiator connections.
Corner sets are handed. Choose left-hand or right-hand according to the end of the radiator the valve head will sit at. If in doubt, send us a photo of the pipework and we will confirm the right hand before ordering.
| Finish | Price per set ex VAT |
|---|---|
| Polished brass, left- or right-hand | £226.40 |
| Chrome, left- or right-hand | £246.30 |
Polished brass is unlacquered, so it will mellow to a soft patina over time, as original brass fittings did. For an angled thermostatic set in the same family, for pipes rising from the floor, see the Kentwell thermostatic valve set. You need one set per radiator. Valves carry a 5-year guarantee. Because valves are made to order, we can only accept returns if an item is faulty or damaged in transit.
| Item | Detail |
|---|---|
| Body | Brass |
| Connection | 15mm copper pipe; ½” BSP radiator tail |
| Flow direction | Fit on the flow (not bi-directional) |
| Maximum working pressure | 10 bar |
| Maximum temperature | 100°C |
| Guarantee | 5 years |
The system should be flushed and dosed with inhibitor to BS 7593, and installation should be carried out by a competent heating engineer. See our cast iron radiators and the full range of traditional radiator valves, or call 0333 987 4452.
| Finish | Polished brass, Chrome |
|---|---|
| Hand | Left-hand, Right-hand |
Every product in our cast iron radiator range has a double-sided A4 technical data sheet, written for architects, specifiers and heating engineers. It includes dimensioned drawings, outputs at ΔT50 and ΔT30, weights, water content, fixing details and a model specification clause you can copy into your specification.
Send us your room heat losses and we will prepare a radiator schedule for your project. Call 0333 987 4452.
