Price range: £113.40 through £182.90 ex VAT (£136.08 – £219.48 inc VAT)
Cast iron square pipe ornamental earband (Pattern G) for 75mm x 75mm and 100mm x 100mm square rainwater downpipes on period, listed and traditional buildings.
UK delivery from £30. Fittings are despatched boxed. See delivery rates.
The Square Pipe Ornamental Earband Pattern G is a decorative cast iron collar for square downpipes, with fleur-de-lis fixing ears with a raised central rib. It is specified on conservation and listed building projects where Pattern G matches the surviving ornamental earbands on the original installation, so the restored elevation keeps the correct decorative detail.
Ornamental earbands were a standard feature on formal Victorian and Edwardian facades, including civic buildings, churches, large commercial premises and institutional architecture, where the downpipe run was treated as part of the architectural composition. Cast to BS 460:2002 and available for 75mm x 75mm (3″ x 3″) and 100mm x 100mm (4″ x 4″) square pipe, in primer or black painted finish. Linseed oil and heritage colour finishes are available on request. For specification support, call 0333 987 4452.
| Size/Finish | Primer 75mm x 75mm, Primer 100mm x 100mm, Black Painted 75mm x 75mm, Black Painted 100mm x 100mm |
|---|
Traditional Express (TX) is a cast iron push-fit soil system. Socketless pipes are joined with push-fit sockets and couplings using rubber seals, so there is no caulking on site. LCC uses caulked socket-and-spigot joints and a bitumen coating. TX is quicker to install and can be painted; LCC is the closer match to an original Victorian stack. Our Traditional Express vs LCC guide compares the two in detail.
The School Board Airbrick (F020801AFC) is available in three standard sizes: 225mm × 75mm, 225mm × 150mm, and 225mm × 225mm. These correspond to one-, two-, and three-brick-course heights and allow ventilation requirements to be met across a range of subfloor and wall opening sizes.
Our cast iron hopper heads are available in a choice of finishes including primer, painted, and specialist heritage finishes. Please call us on 0333 987 4452 or submit an enquiry to discuss the right finish for your project.
Eared LCC pipe is fixed through ears cast on the socket. Plain LCC pipe is fixed with holdfasts driven into the mortar joint, screw-to-wall holderbats, build-in holderbats or loose ears. Fix every length below the socket so each joint is supported. Traditional Express uses adjustable brackets.
Prices are shown on the product page. For project quantities, specification support, or a formal quotation, call 0333 987 4452 or use the contact form.
Our standard spike or sturt length is 300mm (12″). Other sizes are available upon request.
Yes. Cast iron rainwater goods are widely accepted by conservation officers and historic environment bodies as the appropriate material for listed buildings. Tuscan Foundry's hopper heads are manufactured in solid cast iron to BS 460 specification and are suitable for all listed building grades. A linseed oil paint finish is also available, which is particularly appropriate for conservation projects.
The School Board Airbrick is suited to Victorian and Edwardian terraced housing, mid-century school buildings, civic halls, public baths, and converted institutional buildings. Its plain square-grid face matches the utilitarian aesthetic of late-Victorian construction and is also appropriate for new heritage-style builds in conservation areas.
Tuscan Foundry supplies screw-jack rooflight openers in polished brass, satin chrome, and polished chrome finishes. Options include telescopic hand-winder openers in 150mm, 250mm, and 300mm sizes, fixed screw-jack stays, and pole-operated handles for high-level rooflights. All are designed for timber-framed rooflights and skylights.
The Ornamental Airbrick is most appropriate on Victorian Gothic buildings — churches, chapels, vicarages, almshouses, collegiate buildings, and high-specification estate architecture — where decorative ironwork was part of the original design. It suits listed building replacements in kind and heritage new build where period accuracy in detailing is expected.
