Price range: £82.50 through £145.40 ex VAT (£99.00 – £174.48 inc VAT)
A genuine cast iron rainwater pattern the G46 or No.46 is available in two profile sizes. The profile is a larger version of the more traditional ogee (OG) curved pattern and offers increased capacity.
UK delivery from £30. Fittings are despatched boxed. See delivery rates.
The cast iron G46 moulded gutter drop end outlet provides a downpipe connection at the end of a G46 gutter run, used where the run terminates and drainage drops to a downpipe from the end section rather than from a central nozzle outlet. The G46 moulded profile is maintained at the terminal point, completing the installation consistently on the large Victorian and Edwardian properties where this pattern is standard.
Manufactured in solid cast iron to BS 460:2002. Available in both G46 profile sizes: 125mm (5″) and 150mm (6″). Supplied in primed or factory black finish. The G46 drop end outlet is not interchangeable with common ogee fittings.
Specified on listed buildings and heritage restoration projects where the G46 moulded pattern is the historically correct profile. Accepted by conservation officers as the appropriate fitting for period rainwater work.
Compatibility: G46 moulded cast iron gutter 125mm and 150mm only. For specification support, call 0333 987 4452.
| Size/Finish | Black 125mm x 100mm to 100mm x 75mm Rect Out, Black Painted 125mm x 100mm to 100mm Out, Black Painted 125mm x 100mm to 65mm Out, Black Painted 125mm x 100mm to 75mm Out, Primer 100mm x 75mm to 65mm Out, Primer 100mm x 75mm to 75mm Out, Primer 125mm x 100mm to 65mm Out, Primer 125mm x 100mm to 75mm Out, Primer 125mm x 100mm to 100mm x 75mm Rec Out, Primer 125mm x 100mm to 100mm Out, Black Painted 100 x 75mm to 65mm Out, Black Painted 100 x 75mm to 75mm Out |
|---|---|
| Socket | Internal, External |
Cross-reference
| Primer 100mm x 75mm to 65mm Out | G4321A (ext) / G4322A (int) |
| Primer 100mm x 75mm to 75mm Out | G4321B (ext) / G4322B (int) |
| Primer 125mm x 100mm to 65mm Out | G5421A (ext) / G5422A (int) |
| Primer 125mm x 100mm to 75mm Out | G5421B (ext) / G5422B (int) |
| Black Painted 100 x 75mm to 65mm Out | XG4321A (ext) / XG4322A (int) |
| Black Painted 100 x 75mm to 75mm Out | XG4321B (ext) / XG4322B (int) |
| Black Painted 125mm x 100mm to 65mm Out | XG5421A (ext) / XG5422A (int) |
| Black Painted 125mm x 100mm to 75mm Out | XG5421B (ext) / XG5422B (int) |
| Black 125mm x 100mm to 100mm x 75mm Rect Out | XG5421A (ext, 65mm outlet) / XG5421B (ext, 75mm outlet) / XG5422A (int, 65mm outlet) / XG5422B (int, 75mm outlet) |
Yes. Decorative cast iron and brass ventilation grilles of this pattern were widely used in Victorian and Edwardian buildings, and like-for-like replacements are generally accepted by conservation officers for listed building works. We can provide product specifications and material details to support listed building consent applications if required.
Prices vary depending on size and finish. To get a quotation, please call 0333 987 4452 or use the contact form on the Tuscan Foundry website. The team can advise on the right specification for your project and provide a written quote.
BS 460:2002 is the British Standard governing cast iron rainwater goods — gutters, pipes, and fittings. It sets the dimensional tolerances, materials, and performance requirements a component must meet, so that joints seal, sections align, and the system performs as a whole rather than as isolated parts. All Tuscan Foundry Products components are manufactured to comply with BS 460:2002, which is worth citing directly in specification documents and listed building consent applications. The same manufacturing standard applies to bespoke and copy-cast work, even where the profile itself isn't from our standard range.
Please call 0333 987 4452 or use the contact form with the size, quantity and connection details, and we'll provide a quotation.
The louvre face provides directional airflow and offers some resistance to driven rain entering the subfloor void, making it a practical choice for exposed elevations or properties in areas with significant prevailing wind and rainfall. The square-grid (school board) pattern offers a larger open ventilation area but less weather protection.
Yes. A polished brass finish is historically appropriate for period buildings and is generally acceptable to conservation officers for listed building projects. If you are unsure about the specification requirements for your project, we are happy to advise — call 0333 987 4452.
Rooflight opener handles are available in polished brass, polished chrome, and satin chrome finishes. The polished brass version is the most popular choice for heritage and period interiors. For the full range, visit tuscanfoundry.com or call 0333 987 4452.
Cast iron hopper heads from Tuscan Foundry are available in Standard Black (a factory-applied primer and topcoat finish) and Heritage Colours. A linseed oil paint finish is also available, providing a vapour-permeable, historically authentic coating that is particularly appropriate for listed buildings and conservation projects. Full finish specifications are available from the team.
The School Board Airbrick (F020801AFC) is available in three standard sizes: 225mm × 75mm, 225mm × 150mm, and 225mm × 225mm. These correspond to one-, two-, and three-brick-course heights and allow ventilation requirements to be met across a range of subfloor and wall opening sizes.
Our cast iron hopper heads are available with 65mm, 75mm and 100mm round outlets, 75mm, 100mm and 125mm square outlets, and 100x75mm, 125x100mm and 150x125mm rectangular outlets, to match the downpipe already on site or specified for the project.
